Vestil Telescopic Forklift Boom with Tilt
If you’re looking to transform your forklift into a multi-functional lifting device,
Vestil
’s
Orbit Forklift Boom
range is just the ticket.
Manufactured from high-strength structural steel, with faultless welding that meets AWS, this range of forklift booms have been expertly designed to easily withstand rigorous usage in the most demanding industrial environments.
Highly durable and rugged to ensure an extended service life, this range is available in
safe working load limits from 3,000lbs right up to 8,000lbs
.
Featuring a telescopic design and a
37-degree maximum tilt
, enabling you to manoeuvre into the most awkward spaces, the LM-OBT series has an
overall extended length of 146-5/8
”, complete with two lifting hooks for easy and sturdy attachment to you load.
Each unit comes supplied (also available for download) with a
Certificate of Compliance
and Capacity Verification that certifies that every complies with all applicable U.S. Federal OSHA regulations and U.S national standards. NOTE: The end-user bears all responsibility to ensure safe operation, and normal operability through regular testing and inspection, in accordance with the instructions provided with each unit.
The range of Vestil
Orbit
Forklift Lifting Booms
is the perfect combination of performance, convenience, compliance, and safety.
- Safe Working Load Limit range: 3,000lbs - 8,000lbs
- Manufactured from structural steel
- 37-degree maximum tilt
- High visibility colourway (yellow and blue)
- Two lifting hooks
- Fully compliant
- Supplied with Certificate of Compliance
| Fork Mounted Lift Master Booms | ||||||||
| Model Number | Image | Fork Pocket Center |
Overall
Extended Length |
Height | Uniform Capacity (lbs) |
Wt.
(lbs) |
||
|
Telescoping Style |
||||||||
| LM-OBT-3-24 |
|
24" | 146-5/8" | 27-11/16" | 3,000 | 432 | ||
| LM-OBT-4-30 |
|
30" | 146-5/8" | 27-11/16" | 4,000 | 467 | ||
| LM-OBT-4-36 |
|
36" | 146-5/8" | 27-11/16" | 4,000 | 497 | ||
| LM-OBT-4-24 |
|
24" | 146-5/8" | 27-11/16" | 4,000 | 463 | ||
| LM-OBT-6-30 |
|
30" | 146-5/8" | 27-11/16" | 6,000 | 498 | ||
| LM-OBT-6-36 |
|
36" | 146-5/8" | 27-11/16" | 6,000 | 514 | ||
| LM-OBT-6-24 |
|
24" | 146-5/8" | 27-11/16" | 6,000 | 476 | ||
| LM-OBT-8-24 |
|
24" | 148-1/2" | 28-7/8" | 8,000 | 622 | ||
| LM-OBT-8-30 |
|
30" | 148-1/2" | 28-7/8" | 8,000 | 755 | ||
| LM-OBT-8-36 |
|
36" | 148-1/2" | 28-7/8" | 8,000 | 754 | ||
